Product Description

Specification:Item Type: Controller Development BoardMaterial: ResinMain Control: For ATMEGA328P PUSerial Chip: For Atmega16u2Input Voltage: 6-12VWorking Voltage (output current): 5V (500mA)3.3V Maximum Output Current: 150mAMain Frequency: External crystal oscillator 16MFlash: 32K (0.5k for boot): 2KERROM: 1KNumber of Digital IOs: 14PWM: 6ADC: 6 Channels 10BitReference Voltage And Accuracy: 1.1V±0.2%DAC: NoneI Or O DC Output Capability: 20mAFor Bootloader Burning Method: SPIHow to Use:After getting the board, first confirm whether it is normal, that is, connect the board to the computer with a USB cable, and then the green power light (ON) on the right should be on, and the yellow light (L) to for ATmega16U2 is also flashing quickly, After a few seconds, the LED will flash once every two seconds, because the process for that comes with the IDE has been burned before storage (the installation driver will be introduced below).Program burning:Install the serial driver. Connect the R3 to the computer with a USB cable, you need to install the driver, the driver is in the decompressed ..‑1.0drivers.Select the serial port number: After the driver installation is complete, click the Tools button in the menu bar of the development environment, select Serial Port from the drop down menu, and then select the serial port number of the driver just installed.Board Selection: When using R3, you should select the first, click the Tools button in the menu bar of its development environment, select the drop down menu Boards, and then the board.Compile: Click the Verify button on the toolbar, and the window below the development environment will display the space occupied by the program.Burning: Click Upload on the toolbar, and the window below will display Done uploading to indicate that the burning is complete.Result: After the programming is completed, the green LED
